3.2.9.5 Standard report for Siemens DPM
Note
Grades and evaluations in the standard report for Siemens DPM
The standard report for Siemens DPM only contains the grades and evaluations whose quality
characteristics are activated in the WBM.
With the default setting, activated quality characteristics include all characteristics except for
"Symbol contrast" and "Cell size".
Table 3- 14 Output parameters: Siemens DPM
Field name (String input)
Value
Verification type (Qt)
5
If the exposure settings do not comply with the
standard: F
Evaluation (Qs)
3 (Good), 2 (Fair), 1 (Poor)
Overall grade (Q0)
4 ... 0
Contrast grade (Q1)
4 ... 0
Contrast (q1)
0 ... 100
Axial non-uniformity grade (Q2)
4 ... 0
Axial non-uniformity (q2)
0.00 ... 1.00
Unused error correction grade (Q4)
4 ... 0
Unused error correction (q4)
0.00 ... 1.00
Cell modulation grade (Q6)
4 ... 0
Cell modulation 1 (q6)
0 ... 100
Cell modulation 2 (q6)
0 ... 100
Print growth grade (Q9)
4 ... 0
Print growth X (q9)
-100 ... 100
Print growth Y (q9)
-100 ... 100
Cell size grade (Q10)
4 ... 0
Cell size (q10)
0.0 ... 99.9 mil
Center offset grade (Q19)
4 ... 0
Center offset (q19)
0.0 ... 99.9
Size offset grade (Q20)
4 ... 0
Size offset (q20)
0.0 ... 99.9
Border match grade (Q21)
4 ... 0
Border match (q21)
0 ... 100
Angle of distortion grade (Q22)
4, 3, 0
Angle of distortion (q22)
-45 ... 45.0
ECCLevel (q14)
200
Height (q15)
0 ... 9.99 inch
Width (q16)
0 ... 9.99 inch
Angle (q17)
0 ... 360°
