Image processing
3.2 Code verification
SIMATIC MV500
74 Operating Instructions, 03/2021, C79000-G8976-C494-05
Field name (String input)
Value
Start quiet zone (q29)
10 values: 0.00 ... 10.00
Stop quiet zone (q30)
10 values: 0.00 ... 10.00
Nominal module size (q10)
0 to 99.9 mil
Aspect ratio 1 (q31)
1.00 ... 5.00
Aspect ratio 2 (q32)
1.00 ... 5.00
Aspect ratio 3 (q33)
1.00 ... 5.00
Height (q15)
0 to 9.99 inches
Width (q16)
0 to 9.99 inches
Angle (q17)
0 ... 360°
3.2.9.7 Standard report for DotCode
Table 3- 16 Output parameters: DotCode
Field name (String input)
Value
Verification type (Qt)
9
Evaluation (Qs)
3 (Good), 2 (Fair), 1 (Poor)
Overall grade (Q0)
4 ... 0
Contrast grade (Q1)
4 ... 0
Contrast (q1)
0 ... 100%
Grid non-uniformity grade (Q3)
4 ... 0
Grid non-uniformity (q3)
0.00 ... 1.00
Unused error correction grade (Q4)
4 ... 0
Unused error correction (q4)
0.00 ... 1.00
Print growth grade (Q9)
4 ... 0
Print growth (q9)
0.00 ... 1.40
Cell size grade (Q10)
4 ... 0
Cell size (q10)
0.0 ... m.n pixels
3.2.9.8 Standard report for Locator
The standard report uses Locator grades when Locator steps are used.
Table 3- 17 Output parameters: Locator
Field name (String input)
Value
Verification type (Qt)
8
Match (q50)
0 ... 100
Conformity (q51)
0 ... 100
