10.1.4 Read and verification error messages
If a read error or verification error occurs, the following error codes and error messages are
output. You can find additional information in the section "Overall result" of the online help.
Note
The causes of error 4700 to 4722 are also output in the verification report if there is a
verification erro
r
All verification grades are output in the report as "E". The verification values correspond to the
error code.
Note
Evaluating verification errors as read errors
If the "Evaluate 'Poor' evaluation as 'N_OK'" check box has been selected in the
decoding
settings, a verification error will also be evaluated as "N_OK".
Table 10- 3 Read/verification error messages
Error code
(%c)
Error message
(%s)
Description
0001
No 1D/2D code found in step n
No code was found in step #n.
0002
Cycletime too short
The processing was not completed within the cycle
time limit.
0003
Trigger too fast
The processing was interrupted by a trigger signal.
0004
Non ECC200 Code in step n
A data matrix code was found in step #n that does not
correspond to ECC200.
Note:
The check for ECC200 is performed only in adjustment
mode and during "Save program".
0005
Step n: Structured Append DMC not supported
In step #n, a "Structured Append" DMC type was
found. This DMC type is not supported.
0006
Step n: Reader Programming DMC not supported
In step #n, a "Reader Programming Code" DMC type
was found. This DMC type is not supported.
0007
Step n: QR ECI encoding not supported
In step #n, a QR code with "ECI encoding" was found.
This QR type is not supported.
0008
Step n: QR Byte encoding not supported
In step #n, a QR code with "Byte encoding" was found.
This QR type is not supported.
0009
Step n: QR Kanji encoding not supported
In step #n, a QR code with "Kanji encoding" was found.
This QR type is not supported.
0010
Step n: Structured Append QR code not supported
In step #n, a "Structured Append" QR type was found.
This QR type is not supported.
0011
Step n: QR FNC1 encoding not supported
In step #n, a QR code with "FNC1 encoding" was
found. This QR type is not supported.
0012
Code quality is poor in step n
A code with "poor" quality evaluation was read in
step #n during verification.
0013
Nothing found
In "Scan" or "Auto-trigger" mode (edge-controlled): All
image acquisitions were decoded without result.
