Siemens SIMATIC MV500 - Technical data; 11.1 Technical specifications of SIMATIC MV500; Suitability; Interfaces

SIMATIC MV500
Operating Instructions, 03/2021, C79000-G8976-C494-05
245
Technical data
11
11.1 Technical specifications of SIMATIC MV500
Table 11- 1 Technical specifications of the SIMATIC MV500 optical reader
6GF3540-0xx10
6GF3550-0xx10
6GF3560-0xx10
Product type designation
SIMATIC MV540
SIMATIC MV550
SIMATIC MV560
Suitability
Suitability in use
1D codes: Int. 2/5, Code 128, Code 93, Code 39,
Code 32, Codebar, EAN 13, EAN 8, UPC-A, UPC-E,
GS1, Pharmacode, Postnet, 2D codes: DMC, dot
code, PDF417 (without: Truncated, Micro and
Macro), QR (without: Micro and Macro)
Interfaces
Combination interface
Power supply, DI/DQ, RS232 and CM
(M12, 12-pin)
Ethernet interface
• 1x Power over Ethernet
(M12, 4-pin)
• MV550/MV560: 1x Ethernet interface
(M12, 8-pin)
Number of digital inputs
1
Number of digital outputs
3
Design of digital inputs
1 fast trigger input
Design of digital outputs
1 high-speed strobe output for external lighting,
2 isolated outputs, short-circuit-proof, max. 100
mA,
Optical data
Design of image sensor/camera
• Device version S:
CMOS 0.5 Megapixel; 800 × 600
• Device version H:
CMOS 1.3 Megapixel; 1280 × 1024
• Device version U:
CMOS 2.3 Megapixel; 1920 × 1200
• Device version X:
CMOS 5.3 Megapixel; 2592 × 2048
