Scope of delivery and ordering data
13.3 Accessories
SIMATIC MV500
268 Operating Instructions, 03/2021, C79000-G8976-C494-05
13.3.4 Protective lens barrels
The following protective lens barrels are compatible with the lenses and ring lights
mentioned in this manual. Please note that, when using some lenses, you need a protective
lens barrel extension or a "protective lens barrel long" in addition.
Table 13- 9 Protective lens barrel for built-in ring lights for SIMATIC MV500
Protective lens barrel (glass)
for SIMATIC MV500
• Degree of protection: IP67
• Front pane: Glass
• Dimensions (∅ × L): 65 × 65 mm
• Inner diameter: 60.4 mm
• Max. lens length
with built-in ring light: 44.7 mm
without built-in ring light: 47.9 mm
• Suitable for filters
M58 × 0.75; with IP67
Protective lens barrel (PMMA)
for SIMATIC MV500
Features same as protective lens barrel
(glass) with the following differences:
Protective lens barrel (red)
for SIMATIC MV500
Features same as protective lens barrel
(glass) with the following differences:
• Wave length of protective lens barrel:
Protective lens barrel (IR)
for SIMATIC MV500
Features same as protective lens barrel
(glass) with the following differences:
• Wave length of protective lens barrel:
845 - 885 nm
Protective lens barrel (IR, UV, cut)
for SIMATIC MV500
Features same as protective lens barrel
(glass) with the following differences:
• Wave length of protective lens barrel:
390 - 690 nm
Protective lens barrel (long)
Protective lens barrel long (glass)
for SIMATIC MV500
Features same as protective lens barrel
(glass) with the following differences:
Dimensions (∅ × L): 65 × 100.6 mm
Protective lens barrel long
(PMMA)
for SIMATIC MV500
Features same as protective lens barrel
(PMMA) with the following differences:
Dimensions (∅ × L): 65 × 100.6 mm
