Process interfacing via an automation system (PLC, PC)
9.4 Control with FB 79
SIMATIC MV500
Operating Instructions, 03/2021, C79000-G8976-C494-05
193
The "DONE" parameter then has the value "TRUE" and "ACTIVE" the value "FALSE".
Note
No edge change detected
Because the job completes in one CPU cycle, no edge change can be detected at the "ACTIVE"
parameter. If the "DONE" parameter already has the value "TRUE" from a previous job, it is
also not possible to detect an edge change.
Sequence when resetting the DISA bit ("COMMAND" = W#16#0005)
The block resets the "DISA" bit in the control byte of the optical reader. The "DONE" parameter
then has the value "TRUE" and "ACTIVE" the value "FALSE".
Note
No edge
change detected
Because the job completes in one CPU cycle, no edge change can be detected at the "ACTIVE"
parameter. If the "DONE" parameter already has the value "TRUE" from a previous job, it is
also not possible to detect an edge change.
Sequence of the read jobs ("COMMAND = W#16#0081 ... W#16#008F")
Table 9- 48 Possible values of the "COMMAND" parameter for the read jobs
Value (W#16#...)
Meaning
0081
Output result string
0082
Output absolute quality characteristics
0083
Output absolute quality characteristics and output result string
0084
Output quality characteristics as classes
0085
Output quality characteristics as classes and output result string
0086
Output quality characteristics as classes and in absolute format
0087
Output quality characteristics as classes and in absolute format and output result
string
0088
Output code position
0089
Output code position and result string
008A
Output code position and output absolute quality characteristics
008B
Output absolute code position and quality characteristics and output result string
008C
Output code position and quality characteristics as classes
008D
Output code position and quality characteristics as classes and output result string
008E
Output code position and quality characteristics as classes and in absolute format
008F
Output code position and quality characteristics as classes and in absolute format
and output result string
The read jobs can only be sent when the optical reader is not in RUN mode (see also the
operating state table following the parameter table).
