Technical data
11.1 Technical specifications of SIMATIC MV500
SIMATIC MV500
Operating Instructions, 03/2021, C79000-G8976-C494-05
247
6GF3540-0xx10
6GF3550-0xx10
6GF3560-0xx10
Design, dimensions and weight
Dimensions (W × H × D)
68 × 122 × 45 mm
Weight
0.55 kg
Type of mounting
4 x M4 screws
LED display design
7 LEDs
Standards, specifications, approvals
Approvals
CE
MTBF
MV540: 31 years
MV550/MV560: 30 years
1)
Using C-mount lenses and lens accessories, the range can be exactly matched to the application.
2)
You can find detailed information on operating distances with EF lenses in the section "Mounting
with built-in ring light and EF lens".
3)
Not tested by UL. The device was tested by UL only for indoor use.
