Scope of delivery and ordering data
13.3 Accessories
SIMATIC MV500
Operating Instructions, 03/2021, C79000-G8976-C494-05
271
Cables
Description
Article number
Industrial Ethernet connecting
cable
M12-180 / M12-180
• Pre-fabricated IE FC trailing
cable GP
2 x 2 (PROFINET Type C)
• M12 connector, 4-pin (D-
coded)
double-sided
• Degree of protection
IP65/IP67
0.3 m
6XV1870-8AE30
0.5 m
6XV1870-8AE50
1 m
6XV1870-8AH10
1.5 m
6XV1870-8AH15
2 m
6XV1870-8AH20
3 m
6XV1870-8AH30
5 m
6XV1870-8AH50
10 m
6XV1870-8AN10
15 m
6XV1870-8AN15
Industrial Ethernet connecting
cable
M12-180 / RJ45-180
• Pre-fabricated IE FC TP trail-
ing cable GP 2 x 2 (PROFINET
Type C)
• M12 connector, 4-pin (D-
coded)
• IE FC RJ45 connector
• Degree of protection
IP65/IP67
2 m
6XV1871-5TH20
3 m
6XV1871-5TH30
5 m
6XV1871-5TH50
10 m
6XV1871-5TN10
15 m
6XV1871-5TN15
For Ethernet interface "X2 LAN2"
Industrial Ethernet
connecting cable
M12-90 / M12-90
• Pre-fabricated flexible IE
cable 4 x 2
• M12 connector, 8-pin (X-
coded)
double-sided
• Degree of protection
IP65/IP67
0.3 m
6XV1878-5GE30
0.5 m
6XV1878-5GE50
1 m
6XV1878-5GH10
1.5 m
6XV1878-5GH15
2 m
6XV1878-5GH20
3 m
6XV1878-5GH30
5 m
6XV1878-5GH50
10 m
6XV1878-5GN10
15 m
6XV1878-5GN15
The cables are supplied with M12 plugs fitted at both ends. When necessary, the cables can
be shortened at the other end from the optical reader and adapted with the following
connectors, for example, for an RJ45 infrastructure:
Table 13- 14 Industrial Ethernet connector FC RJ45
Connector Description Article number
IE connector
FC RJ45 connector 180°
(2x2)
• RJ45 plug-in connector for
Industrial Ethernet (10/100
Mbps)
• With integrated insulation
displacement contacts
• 180° cable outlet
• For network components
and CPs/CPUs
1 unit
6GK1901-1BB10-2AA0
10 units
6GK1901-1BB10-2AB0
50 units
6GK1901-1BB10-2AE0
