Image processing
3.2 Code verification
SIMATIC MV500
66 Operating Instructions, 03/2021, C79000-G8976-C494-05
Verification report
Through the input of "%R" in the format string, you receive a verification report containing
the overall quality and information on the lighting used. The precise formatting and the
values contained depend on the verification standard that was used and are defined in the
specific standard.
Note
Availability of the verification report
Values enclosed in square brackets are optional.
The verification report is not available for verification according to ISO/IEC
16022, AS 9132
• Output for ISO/IEC 15415:
<overall grade>/<aperture or cell size>/<wavelength>/[<radiation angle ≠ 45°>]
• Output for ISO/IEC 29158:
DPM<overall grade>/<percentage aperture>/<wavelength>/[<radiation angle ≠ 45°>]
• Output for ISO/IEC 15416:
<overall grade>/<module size>/<wavelength>/
Verification settings
Through the input of "%v" in the format string, you receive an output of all output parameters
relevant for verification in the printed order.
All field values are separated by semicolons. The field names are not part of the report.
Table 3- 9 Output parameters of the verification
Brightness offset (coarse)
