Siemens SIMATIC NET PROFIBUS User Manual

Passive Components for RS-485 Networks
4-33
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
4.3.1 Area of Application and Technical Specifications of the Bus
Connector
Uses
You require bus connectors to attach the PROFIBUS LAN cable to 9-pin sub-D
interfaces. There are various bus connectors with the degree of protection IP 20
and the situations in which they are used are listed in Table 4-6.
Table 4-6 Design and Applications of the IP 20-compliant Bus Connectors
Order
numbers:
6ES7 972-0BA11-0XA0
6ES7 972-0BB11-0XA0
6ES7 972-0BA40-0XA0
6ES7 972-0BB40-0XA0
6ES7
0BA30-0XA0
6GK1
500-0EA02
Appearance:
35_ cable outlet 30_ cable outlet
SIEMENS
Recommended
for:
S IM 308-B
S IM 308-C
S S5-95U
~ (version 6 or higher)
~
~
~
~
~
~
~
Use in PLC with
integrated
interface:
S S7-300
S S7-400
S M7-300
S M7-400
~
~
~
~
~
~
~
~
~
~
~
Use in PLC with
S IM 308 C
S CP 5431
FMS/DP
S CP 342-5
S CP 343-5
S CP 443-5
~
~
~
~
~
~
~
~
~
~
~
~
~
~
~
Use in PG with
MPI interface
~
Use in PG with
S CP5412(A2)
S CP 5411
S CP 5511
S CP 5611
S CP 5613/14
~
~
~
~
~
