Siemens SIMATIC NET PROFIBUS User Manual

Topologies of SIMATIC NET PROFIBUS Networks
2-4
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
2.1.2 Components for Transmission Rates up to
12 Mbps
The following bus attachment components can be used for transmission rates up
to 12 Mbps:
Table 2-1 Bus Attachment Components for Transmission Rates up to 12 Mbps
Order number
PROFIBUS bus connector with
axial cable outlet
6GK1 500-0EA02
PROFIBUS FastConnect bus connector RS-485
Plug 180
with 180° cable outlet 6GK1500-0FC00
RS-485 bus connector with vertical cable outlet
Without PG interface
With PG interface
6ES7 972-0BA11-0XA0
6ES7 972-0BB11-0XA0
PROFIBUS FastConnect RS-485 bus connector
with 90° cable outlet with insulation displacement terminal
system
max. transmission rate 12 Mbps
Without PG interface
With PG interface
6ES7 972-0BA50-0XA0
6ES7 972-0BB50-0XA0
RS-485 bus connector with 35
o
cable outlet
Without PG interface
With PG interface
6ES7 972-0BA40-0XA0
6ES7 972-0BB40-0XA0
SIMATIC NET 830-1T connecting cable, preassembled, fitted
with terminating resistors, as link between electrical interface
of an OLM or OBT and the PROFIBUS interface of a
PROFIBUS node.
1.5 m
3 m
6XV1830-1CH15
6XV1830-1CH30
SIMATIC NET 830-2 connecting cable for PROFIBUS,
preassembled cable with two sub-D, 9-pin male connectors,
terminating resistors can be activated.
3 m
5 m
10 m
6XV1830-2AH30
6XV1830-2AH50
6XV1830-2AN10
SIMATIC S5/S7 PROFIBUS connecting cable
for connecting programming devices up to 12 Mbps
preassembled with 2 sub-D connectors, length 3 m 6ES7 901-4BD00-0XA0
PROFIBUS RS-485 repeater 24 V DC, casing with IP 20
degree of protection
6ES7 972-0AA01-0XA0
Bus terminal BT12M 6GK1 500-0AA10
Optical Link Module OLM V3 6GK1 502-_C_00
