Dimension Drawings
F-5
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
F.2 Dimension Drawings of the RS-485 Repeater
73
125
128
45
Figure F-7 RS–485 Repeater on Standard Rail
125
70
45
Figure F-8 RS-485 Repeater on S7-300 Rail
