Dimension Drawings
F-4
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
16
36
35
11.6
72.7
Figure F-5 FastConnect Bus Connector (6ES7 972–0B.50–0XA0)
28.4
34.3
61.75
44.1
15.8
Figure F-6 FastConnect Bus Connector (6GK1 500–0FC00)
