Dimension Drawings
F-6
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
F.3 Dimension Drawing of the PROFIBUS Terminator
PROFIBUS
TERMINATOR
6ES7 972-0DA00-0AA0
DC
24 V
L+ M PE A1 B1
SIEMENS
70
60
29.6
40.3
44.5
Figure F-9 PROFIBUS Terminator
