Dimension Drawings
F-7
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
F.4 Dimension Drawings of the RS-485 Bus Terminal
138
53
SINEC L2
PG/OP
Bus Terminal
RS 485
64
84
50
Figure F-10 RS-485 Bus Terminal on 15 mm high Standard Rail
