Dimension Drawings
F-11
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
F.7 Dimension Drawings Infrared Link Module ILM
SIEMENS
PRLFIBUSILM
30
175
80
60
57.5
87.5
15
Figure F-14 PROFIBUS ILM
1
1
5
2
163
Mounting
drill hole 1
Mounting
drill hole 2
Figure F-15 Drilling Dimensions for Securing the PROFIBUS ILM to a Mounting Plate
