Siemens SIMATIC NET PROFIBUS - F.6 Dimension Drawings of the Optical Bus Terminal OBT

Dimension Drawings
F-9
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
F.6 Dimension Drawings of the Optical Bus Terminal OBT
138
86
SIMATIC NET
Optical
Bus Terminal
64
50
Figure F-12 Optical Bus Terminal OBT on 15 mm high Standard Rail
