Dimension Drawings
F-10
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
CH1
SIMATIC NET
PROFIBUS
Optical
Bus Terminal
6GK1500–3AA00
1 2 3 4 5 6 7
L + 24V
CH1
CH2
CH3
CH2 CH3
PE
M
L+
NEC CLASS2
24VDC, 200 mA
42.5
67.3
Figure F-13 Drilling Template for the Optical Bus Terminal OBT
