Dimension Drawings
F-8
PROFIBUS
Networks SIMA
TIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
F
.5
Dimension
Drawings of the BT12M Bus T
erminal
SIMA
TIC NET
Bus T
erminal 12M
64
84
50
138
53
Figure F-1
1
BT12M Bus T
erminal on 15 mm high Standard Rail
331
333
