Dimension Drawings
F-2
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
F.1 Dimension Drawings of the Bus Connectors
End face of
sub-D male
conn.
End face of
sub-D male
conn.
15.8
8
-0.2
34
10
SIEMENS
on
off
8
-0.2
15.8
34
10
SIEMENS
on
off
without PG socket with PG socket
64
64
25 25
5
5
Figure F-1 Bus Connector to IP 20 (6ES7 972-0B.11-0XA0)
15
34
4
35
10
25
30°
58
End face of
sub-D male
conn.
Figure F-2 Bus Connector to IP 20 (6ES7 972-0BA30-0XA0)
