Dimension Drawings
F-3
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
15.8
8
-0.1
38
8
-0.1
15.8
38
54
54
25 25
5
5
End face of
sub-D male
conn.
10 10
End face of
sub-D male
conn.
35°
35°
without PG socket
with PG socket
Figure F-3 Bus Connector to IP 20 (6ES7 972-0B.40-0XA0)
15
56
35
39
OFF
ON
SIEMENS
10
End face of
sub-D male conn.
Figure F-4 Bus Connector to IP 20 (6GK1 500-0EA02)
