Siemens SIMATIC NET PROFIBUS User Manual

Passive Components for PROFIBUS-PA
6-4
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
How the SpliTConnect Tap Works
The SpliTConnect Tap is used to install a PROFIBUS-PA bus segment complying
with IEC 61158-2 /5/ with DTE attachment points. The FastConnect attachment
system (FastConnect stripping tool, FastConnect LAN cable for IEC 61158-2)
allows straightforward assembly of cables. DTEs can be attached directly via the
FastConnect LAN cable for IEC 61158-2 or via the SpliTConnect M12 outlet.
Table 6-1 Ordering Data:
Ordering Data:
Order no.
SpliTConnect Tap
for implementing PROFIBUS-PA segments and
attaching PA field devices, insulation
displacement terminals, IP 67
Consignment: pack of 10
6GK1 905-0AA00
SpliTConnect M12 Outlet
element for direct attachment of PROFIBUS-PA
field devices to the SpliTConnect tap via the
M12 connector
Consignment: pack of 5
6GK1 905-0AB00
SpliTConnect Coupler
connection element for cascading
SpliTConnect taps to create star hubs
Consignment: pack of 10
6GK1 905-0AC00
SpliTConnect Terminator (Ex)
for terminating PROFIBUS-PA segments, can
be used in hazardous areas
Consignment: pack of 5
6GK1 905-0AD00
SpliTConnect Terminator (not Ex)
for connecting PROFIBUS-PA segments,
cannot be used in hazardous areas
Consignment: pack of 5
6GK1 905-0AE00
