Passive Components for Electrical Networks
7-15
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
Table 7-4 Technical Specifications of the INDOOR Fiber-Optic Cable and Fiber-Optic Standard Cable
Cable Type INDOOR Fiber-Optic
Cable
Fiber-Optic
Standard Cable
Impact strength 3 blows
(initial energy: 5 Nm
hammer radius: 300 mm)
3 blows
(initial energy: 1.5 Nm
hammer radius: 300 mm)
Installation temperature -5°C to +50°C -5°C to +50°C
Operating temperature -25°C to +60°C -20°C to +60°C
Storage temperature -25°C to +70°C -25°C to +70°C
Behavior in fire Flame retardant complying with
IEC 60332-3 cat. CF
Flame retardant complying with
IEC 60332-3 and DIN VDE 0472
Part 804, test type B
Free of halogens no yes
UL approval no no
Ship building approval no no
Table 7-5 Technical Specifications of the Flexible Fiber-Optic Trailing Cable and the SIENOPYR Duplex
Fiber-Optic Marine Cable
Cable Type Flexible Fiber-Optic
Trailing Cable
SIENOPYR
Duplex Fiber-Optic
Marine Cable
Areas of application Flexible cable for installation in a
drag chain indoors and outdoors
Fixed installation on ships and
offshore facilities in all enclosed
spaces and on free decks
Available as Preassembled cable with 4
BFOC connectors in fixed
lengths, also available in meters
Sold in meters
Cable type
(standard designation)
AT-W11Y (ZN)
11Y2G62.5/125
3,1B200+0.8F600 LG
MI-VHH 2G 62.5/125
3.1B200 + 0.8F600 +
2x1CU 300 V
Fiber type Multimode graded fiber 62.5/125
µm
Multimode graded fiber 62.5/125
µm
Power loss at 850 nm
Power loss at 1300 nm
<= 3.1 dB/km
<= 0.8 dB/km
<= 3.1 dB/km
<= 0.8 dB/km
Modal bandwidth at 850 nm
at 1300 nm 200 MHz *km
600 MHz *km
200 MHz *km
600 MHz *km
Number of fibers 2 2
Cable design Splittable
outdoor cable
Splittable
outdoor cable
Core type Hollow core, filled Solid core
Basic element materials PUR, black Polyolefin
