Infrared Link Modul (ILM)
6ZB530–3AC30–0BA1
6
Copyright by Siemens
2 Symbols
LAN cable (twisted pair)
Bus connector
terminating resistor deactivated
Active or (or passive) bus node
Infrared link module (ILM)
terminating resistor deactivated
Important information and notes
Bus connector
terminating resistor activated
+
4
“Sequence of actions” to be performed by the user.
Passive bus node
Slave
ILM
Master
ILM
Infrared link module (ILM)
terminating resistor activated
