Infrared Link Modul (ILM)6ZB5530–3AC30–0BA1
29
Copyright by Siemens
transmission errors.
The red “LOW” LED should only be lit when the level on the infrared link is close to the minimum receive
level (operation at the edge of the illumination cone).
3 Check the data exchange for incorrect data using SCOPE for PROFIBUS (TMG i-tec), a tool for
diagnostics on PROFIBUS networks.
