Infrared Link Modul (ILM)
6ZB530–3AC30–0BA1
48
Copyright  by Siemens
Safety
VDE specifications VDE 0806=EN60950 and IEC950
UL/CSA approval Requirements are met
Climatic environmental conditions
Ambient temperature 0 °C to )60 °C
(IEC 68–2–1, IEC 68–2–2)
Storage temperature –40 °C to )70 °C
(IEC 68–2–14)
Relative humidity < 95% (none condensing)
(IEC 68–2–30)
If condensation forms on the window, there is a tempo-
rary reduction in the distance that can be covered.
There is no permanent functional disturbance and no
damage to the electronics if the threaded cable inlet ful-
fills the requirements of IP65.
Mechanical environmental conditions
Oscillation during operation 10 to 58 Hz, 0.075 mm deflection
58 to 150 Hz, 10 m/s
2
(1g) acceleration
(IEC 68–2–6)
Oscillation during transportation 5 to 9 Hz, 3.5 mm deflection
9 to 500 Hz, 10m/s
2
(1g) acceleration
Degree of protection IP 65
Weight 800 g
Dimensions 175 × 80 × 58 mm
Casing material Die-cast aluminum
Table 4: Environmental Conditions for the Use of the PROFIBUS ILM
