Technical Specifications
7-3
PROFIBUS Optical Bus Terminal (OBT)
C79000-G8976-C122-02
Relative humidity < 95% (no condensation)
(IEC 68–2–30)
Mechanical conditions
Vibration during operation 10 to 58 Hz, 0.075 mm deflection
58 to 150 Hz, 10m/s
2
(1g) acceleration
(IEC 68–2–6)
Vibration during transportation 5 to 9 Hz, 3.5 mm deflection
9 to 500 Hz, 10m/s
2
(1g) acceleration
Type of protection (with external fusing ≤ 8A)
IP 30
Weight 400 g
Dimensions 50.5 x 138 x 78 mm
Casing material Noryle anthracite
