Topologies of SIMATIC NET PROFIBUS Networks
2-39
PROFIBUS Networks SIMATIC NET
6GK1970-5CA20-0AA1 Release 2 05/2000
Configuring
The link module can be configured as a DP slave, for example with the standard
tools STEP 7 or COM PROFIBUS and on the instabus EIB using the configuration
software ETS 2.
S DP
A GSD file is supplied with the manual. The DP slave address is set with a
coding switch on the DP/EIB link.
S instabus EIB
The database entry of the DP/EIB link for instabus EIB configuration software
ETS 2 is supplied with the DP/EIB manual.
For further details, refer to the DP/EIB link manual.
