Interface Modules
6-3
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
6.2 Interface Module IM 360; (6ES7360-3AA01-0AA0)
Order number
6ES7360-3AA01-0AA0
Characteristics
The interface module IM 360 has the following characteristic features:
• Interface for rack 0 of the S7-300
• Data transfer from IM 360 to IM 361 over the connecting cable 368
• Maximum distance between IM 360 and IM 361 is 10 m (32.8 ft.)
Status and fault LEDs
The interface module IM 360 has the following status and fault LEDs.
LED Meaning Explanation
SF Group error/fault The LED lights up if
• the connecting cable is missing.
• IM 361 is switched off.
