Siemens Simatic S7-300 - C-9 Dimension Drawing of the 2000 MM Rail

C-6
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
2000 mm rail
Figure C-9 shows the dimension drawing of the 2000 mm rail.
2000
15
6
122
Figure C-9 Dimension Drawing of the 2000 mm Rail
