8.4 Wiring SIMATIC TOP Connect TPA with Analog Modules
Introduction
For wiring the module with actuators/sensors using SIMATIC TOP connect TPA,
you must first select the components as a function of the method of connection
(screw-type or spring-loaded terminal).
8.4.1 SIMATIC TOP connect TPA Components and Selection Aid
Components
The following table contains all the component of SIMATIC TOP connect TPA.
Table 8-13 Components for SIMATIC TOP connect TPA
Components of SIMATIC TOP connect TPA Order number
Terminal block Quantity: 1 Spring-loaded terminals
Screw-type terminals
6ES7924-0CC00-0AB0
6ES7924-0CC00-0AA0
Quantity: 10 Spring-loaded terminals
Screw-type terminals
6ES7924-0CC00-1AB0
6ES7924-0CC00-1AA0
Front connector Voltage supply via:
Spring-loaded terminals
Screw-type terminals
6ES7921-3AF00-0AA0
6ES7921-3AG00-0AA0
Connectors (plug-in connectors), set of 8 (insulation
displacement connectors)
6ES7921-3BE10-0AA0
Shielding plate for terminal block, set of 4 6ES7928-1BA00-0AA0
Terminal element for:
2 cables, each with a shield diameter of 2 to 6 mm
1 cable with a shield diameter of 3 to 8 mm
1 cable with a shield diameter of 4 to 13 mm
6ES7390-5AB00-0AA0
6ES7390-5BA00-0AA0
6ES7390-5CA00-0AA0
Round-sheath ribbon cable, shielded
∅ 8 mm
30 m
60 m
6ES7923-0CD00-0BA0
6ES7923-0CG00-0BA0
Crimping tool for 16-pin connector 6ES7928-0AA00-0AA0
