Siemens Simatic S7-300 - Front View of the Interface Module IM 361

Interface Modules
6-6
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
Front View
Figure 6-2 shows the front view of the interface module IM 361.
OUT
IN
SF
5 VDC
X1
X2
M
L+
M
Figure 6-2 Front View of the Interface Module IM 361
