Siemens Simatic S7-300 - C.5 Dimension Drawings for Accessories

C-16
Programmable Logic Controllers S7-300 Module Data
A5E00105505-03
C.5 Dimension Drawings for Accessories
Shield connecting element
Figure C-21 shows the dimension drawing of the shield connecting element in
connection with two signal modules.
190
80
40
120
Figure C-21 2 Signal Modules with Shield Connecting Element
