Digital modules

3.14 Digital input module SM 321; DI 16 x UC 24/48 V; (6ES7321-1CH00-0AA0)

S7-300 Module data

Manual, 06/2017, A5E00105505-AJ

107

Technical specifications

Sensor selection data

Input voltage

• Rated value

24 VDC/VAC or 48 VDC/VAC

• "1" signal

• "0" signal

• Frequency band

14 V to 60 V

-5 V to 5 V

0 Hz to 63 Hz

Input current

• "1" signal

• "0" signal

typ. 2.7 mA

-1 mA to +1 mA

Input delay

• "0" to "1" transition

• "1" to "0" transition

max. 16 ms

Input characteristics

to IEC 61131, type 1

Connection of 2-wire BEROs

supported

• Permissible quiescent current

max. 1 mA

Wiring of the signal sensors

using a 40-pin front connector
