Analog modules
6.1 Analog module selection and commissioning sequence
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
301
6.1 Analog module selection and commissioning sequence
Introduction
The table below contains the steps required to successfully complete commissioning of
analog modules.
You do not strictly have to adhere to this suggested sequence, that is, you can complete
other tasks such as installing or commissioning other modules, or program the module at an
earlier or later time.
Analog module selection and commissioning sequence
1. Selecting the module
2. For certain analog input modules: Set the measuring type and range using the measuring
range module
3. Installing the module in the SIMATIC S7 system
4. Assigning module parameters
5. Connect the measuring transducers or loads to the module
6. Commission the configuration
7. Analyze the configuration if commissioning failed
More information on installation and commissioning
See the "Installation" and "Commissioning" chapter in the Installation Manual for your
automation system:
● S7-300 Automation System, Installation or
● S7-400 Automation System, Installation or
● Distributed I/O Device ET 200M
The documentation is available on the Internet
(
http://support.automation.siemens.com/WW/view/en
).
