Siemens SIMATIC User Manual

Principles of analog modules
5.8 Diagnostics of analog modules
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
297
5.8.3 Causes of error and troubleshooting at analog input modules
Overview of the causes of error and troubleshooting at analog input modules
Table 5- 46 Diagnostics messages of analog input modules, causes of error and troubleshooting
Diagnostics message
Possible cause of error
To correct or avoid errors
External load voltage miss-
ing
Load voltage L+ of module missing Connect supply L+
Configuration / program-
ming error
Faulty parameters transferred to module Check the measuring range module
Program the module
Common-mode error Potential difference C
MV
between inputs M-
and the reference potential of measuring
circuit (M
ANA
out of limits)
Connect M- with M
ANA
Wirebreak Resistance of transducer circuit too high Use a different type of sensor, or modify the
wiring, for example, using a larger conductor
cross-section.
Open circuit between module and sensor
Connect the cable
Channel not connected (open) Disable the channel group ("measuring method"
parameter)
Wire the channel
Underflow Input value below undershoot range; pos-
sible cause of error:
wrong measuring range setting
program a different measuring range
polarity reversal of the sensor wiring in the
measuring ranges 4 to 20 mA and 1 to 5 V
Check the connections
Overflow
Input value exceeds overshoot range
program a different measuring range
5.8.4 Causes of error and troubleshooting at analog output modules
Overview of the causes of error and troubleshooting routines at analog output modules
Table 5- 47 Diagnostics messages of analog output modules, causes of error and troubleshooting
Diagnostics message
Possible cause of error
To correct or avoid errors
External load voltage miss-
ing
Load voltage L+ of module missing Connect supply L+
Configuration / program-
ming error
Faulty parameters transferred to mod-
ule
Assign new module parameters
Short-circuit to M
Overload at output
Eliminate overload
Short-circuit at output Q
V
to M
ANA
Eliminate the short-circuit
Wirebreak Actuator impedance too high Use a different type of actuator, or modify the wiring
using cables with a larger conductor cross-section
Wire-break between the module and
actuator
Connect the cable
Channel not used (open)
Disable the channel group ("output type" parameter)
