Analog modules
6.7 Analog input module SM 331; AI 8 x 12 bit;(6ES7331-7KF02-0AB0)
S7-300 Module data
362 Manual, 06/2017, A5E00105505-AJ
Technical specifications
Temperature compensation
• Internal temperature compensation
programmable
supported
• External temperature compensation with compensating
box
supported
• Compensation for 0 °C reference junction temperature
supported
• Technical unit of temperature measurement
degrees Centigrade
See also
Diagnostics messages of analog input modules (Page 296)
6.7.2 Measurement types and ranges
Introduction
Module SM 331; AI 8 x 12 Bit has measuring range modules
The measurement type and range is configured at the "measuring range" parameter in
STEP 7 .
The default setting of the module is "voltage" measurement with "± 10V" range. You can use
these default settings without having to program the SM 331; AI 8 x 12 Bit in
STEP 7 .
Measuring range modules
You may have to change the position of the measuring range modules to suit the
measurement type and range (see the chapter
Setting the measuring types and ranges of
analog input channels
). The necessary settings are also available on the module's imprint.
Mark the position of the measuring range module on the front door (see figure).
