Digital modules
3.32 Digital output module SM 322; DO 8 x AC 120/230 V/2 A ISOL (6ES7322-5FF00-0AB0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
195
Configuration in RUN
Special considerations must be given if you use the Configuration in RUN function.
SF LED is lit:
Status before re-configuration diagnostics on, SF LEDs lit among others (on CPU, IM or
module), although diagnostics are no longer pending and the module is operating correctly.
Solution:
● Only change the configuration when no diagnostics are pending for the module or
● Pulling and plugging the module.
3.32.1 Parameters of SM 322; DO 8 x AC 120/230 V/2 A ISOL
Parameters of SM 322; DO 8 x AC 120/230 V/2 A ISOL
The table below lists the configurable parameters of SM 322; DO 8 x AC120/230 V/2 A
ISOL, including defaults.
The defaults apply if you have not set any parameters in
STEP 7 .
Table 3- 32 Parameters of SM 322; DO 8 x AC 120/230 V/2 A ISOL
Parameters
Range of values
Defaults
Parameter type
Scope
Enable
• Diagnostic interrupts
yes/no no dynamic Module
Reaction to CPU STOP Set substitute value (SSV)
Hold last value (HLV)
SSV dynamic Channel
Set substitute value "1"
yes/no
no
dynamic
Channel
Programming
For detailed information on parameters of the digital output module, refer to the appendix
Settings for the digital output modules (Page 528).
See also
Programming digital modules (Page 58)
