Siemens SIMATIC User Manual

Digital modules
3.38 Digital IO module SM 323; DI 8/DO 8 x DC 24 V/0.5 A; (6ES7323-1BH01-0AA0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
227
3.38 Digital IO module SM 323; DI 8/DO 8 x DC 24 V/0.5 A;
(6ES7323-1BH01-0AA0)
Order number: "Standard module"
6ES7323-1BH01-0AA0
Order number: "SIPLUS S7-300 module"
6AG1323-1BH01-2AA0
Properties
Properties of SM 323; DI 8/DO 8 x DC 24 V/0.5 A:
● 8 inputs, electrically isolated in groups of 8
● 8 outputs, electrically isolated in groups of 8
● Rated input voltage 24 V DC
● Rated load voltage 24 V DC
● Inputs suitable for switches and 2-/3-/4-wire proximity switches (BEROs)
● Outputs capable of driving solenoid valves, DC contactors and indicator lights
Use of the module with high-speed counters
Please note when using the module in combination with high-speed counters:
Note
When using a mechanical contact to switch on the 24
-V power supply to
SM 323; DI 8/DO 8
x DC 24 V/0.5 A, its outputs will carry "1" signal for the duration of ca. 50
µs, due to the circuit structure.
