Page #143 background imageLoading...
Page #143 background image
Digital modules
3.23 Digital output module SM 322; DO 16 x DC 24 V/ 0.5 A; (6ES7322-1BH01-0AA0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
143
3.23 Digital output module SM 322; DO 16 x DC 24 V/ 0.5 A;
(6ES7322-1BH01-0AA0)
Order number: "Standard module"
6ES7322-1BH01-0AA0
Order number: "SIPLUS S7-300 module"
6AG1322-1BH01-2AA0
Properties
Properties of SM 322; DO 16 x DC 24 V/0.5 A:
16 outputs, electrically isolated in groups of 8
Output current 0.5 A
Rated load voltage 24 V DC
Suitable for solenoid valves, DC contactors and signal lamps
Use of the module with high-speed counters
Please note when using the module in combination with high-speed counters:
Note
When us
ing a mechanical contact to switch on the 24-V power supply to SM 322; DO
16
x DC 24 V/0.5 A, its outputs will carry "1" signal for the duration of ca. 50 µs, due to the
circuit structure.
