Siemens SIMATIC User Manual

Digital modules
3.28 Digital output module SM 322; DO 8 x DC 24 V/2 A; (6ES7322-1BF01-0AA0)
S7-300 Module data
170 Manual, 06/2017, A5E00105505-AJ
3.28 Digital output module SM 322; DO 8 x DC 24 V/2 A;
(6ES7322-1BF01-0AA0)
Order number
6ES7322-1BF01-0AA0
Properties
Properties of SM 322; DO 8 x DC 24 V/2 A:
● 8 outputs, electrically isolated in groups of 4
● Output current 2 A
● Rated load voltage 24 V DC
● Suitable for solenoid valves, DC contactors and signal lamps
Use of the module with high-speed counters
Please note when using the module in combination with high-speed counters:
Note
When using a mechanical contact to switch on the 24
-V power supply to SM 322; DO
8
x DC 24 V/2 A, the module outputs will carry a "1" signal for the duration of ca. 50 µs due
to the circuit structure.
