6.3 Analog input module SM 331; AI 8 x 16 bit; (6ES7331-7NF00-0AB0)
S7-300 Module data
314 Manual, 06/2017, A5E00105505-AJ
6.3.2 Programmable parameters
Introduction
For information on programming analog modules, refer to the chapter Programming analog
modules (Page 294).
Parameters
Table 6- 6 Overview of the parameters of SM 331; AI 8 x 16 Bit
Parameters
Range of values
Default
Parameter
type
Scope
Enable
• Diagnostic interrupt
• Hardware interrupt when
limit exceeded
yes/no
yes/no
no
no
dynamic Module
Hardware interrupt trigger
• High limit
• Low limit
May be restricted by the measuring range.
from 32511 to - 32512
from - 32512 to 32511
- dynamic Channel
Diagnostics
• Group diagnostics
• with line continuity check
yes/no
yes/no
no
no
static Channel
group
Measurement
• Measurement type
disabled
Voltage V:
4DMU current (4-wire transducer)
V
dynamic
Channel
group
• Measuring range
See the table
Measurement types and ranges ± 10 V
• Noise suppression
100 Hz; 60 Hz; 50 Hz; 10 Hz 50 Hz
Channel groups
The channels of SM 331; AI 8 x 16 Bit are arranged in four groups of two channels. You can
assign parameters only to one channel group.
