Siemens SIMATIC - Analog IO Module SM 334; AI 4;AO 2 X 12 Bit; (6 ES7334-0 KE00-0 AB0)

Analog modules
6.17 Analog IO module SM 334; AI 4/AO 2 x 12 bit; (6ES7334-0KE00-0AB0)
S7-300 Module data
484 Manual, 06/2017, A5E00105505-AJ
6.17 Analog IO module SM 334; AI 4/AO 2 x 12 bit;
(6ES7334-0KE00-0AB0)
Order number: "Standard module"
6ES7334-0KE00-0AB0
Order number: "SIPLUS S7-300 module"
6AG1334-0KE00-2AB0
Properties
● 4 inputs in 2 groups and 2 outputs in one group
● Resolution of 12 bits + sign
● Programmable measurement type at each channel group:
– Voltage (not adjustable for channel 0 and channel 1)
– Resistance
– Temperature
● Electrically isolated to the backplane bus interface
● Electrically isolated to load voltage
Terminal assignment
The diagrams below show various wiring options.
Note
When you switch the rated load voltage supply on/off, the output may assume invalid interim
values below the rated load voltage.
