Digital modules
3.1 Module overview
S7-300 Module data
52 Manual, 06/2017, A5E00105505-AJ
3.1.2 Digital output modules
Overview of properties
The table below shows the essential properties of the digital output modules
Table 3- 4 Digital output modules
Properties
Module
SM 322; DO 64 x
DC24V/0,3A
Sourcing
(-1BP00-)
SM 322; DO 64 x
DC 24V/0,3A
Sinking
(-1BP50-)
SM 322; DO 32 x
DC24V/0,5A
(-1BL00-)
SM 322; DO 32 x
AC120/230V/1A
(-1FL00-)
SM 322; DO 16 x
DC24V/0,5A
(-1BH01-)
Number of outputs 64 DO; isolated in
groups of 16
64 DO; isolated in
groups of 16
32 DO; isolated in
groups of 8
32 DO; isolated in
groups of 8
16 DO; isolated in
groups of 8
Output current
0.3 A
0.3 A
0.5 A
1.0 A
0.5 A
Rated load voltage
24 V DC
24 V DC
24 V DC
24 V DC
24 V DC
Suitable for...
solenoid valves, DC contactors and signal lamps
Supports isochro-
nous mode
no no No No No
Programmable
diagnostics
No No No No no
Diagnostic interrupt
No
No
No
No
No
Substitute value
output
No No No No No
Special features
-

Siemens SIMATIC Specifications

General

Product type designation	SIMATIC
CPU	Varies by model
Memory	Varies by model
Input/Output	Varies by model
Communication	Varies by model
Programming Language	STEP 7
Operating Temperature	0°C to 60°C (varies by model)
Protection Class	IP20
Category	Programmable Logic Controller (PLC)
