6.14 Analog output module SM 332; AO 4 x 12 Bit; (6ES7332-5HD01-0AB0)
S7-300 Module data
460 Manual, 06/2017, A5E00105505-AJ
6.14 Analog output module SM 332; AO 4 x 12 Bit;
(6ES7332-5HD01-0AB0)
Order number
6ES7332-5HD01-0AB0
Order number: "SIPLUS S7-300 module"
6AG1332-5HD01-7AB0
Properties
● 4 outputs in one group
● The output can be selected by individual channel
– Voltage output
– Current output
● Resolution 12 bits
● Programmable diagnostics and diagnostic interrupt
● Electrically isolated to backplane bus interface and load voltage
● Supports parameter reassignment in RUN
Diagnostics
For information on diagnostic messages at the "group diagnostics" parameter, refer to
chapter Diagnostic messages of analog output modules (Page 296).
Terminal assignment
The diagrams below show various wiring options.
Note
When you switch the rated load voltage (L+) off and on, the outputs can return incorrect
volta
ge/current values for the duration of about 500 ms.
