7.2 Simulator module SM 374; IN/OUT 16; (6ES7374-2XH01-0AA0)
S7-300 Module data
494 Manual, 06/2017, A5E00105505-AJ
7.2 Simulator module SM 374; IN/OUT 16; (6ES7374-2XH01-0AA0)
Order number
6ES7374-2XH01-0AA0
Properties
Properties of simulator module SM 374; IN/OUT 16:
● Simulation of:
– 16 inputs or
– 16 outputs or
– 8 inputs and 8 outputs (each with the same start addresses!)
● Status displays for the simulation of inputs and outputs
● Function adjustable with screwdriver
Note
Do not operate the function selection switch in RUN!
Configuration in STEP 7
The simulator module SM 374; IN/OUT 16 is not included in the STEP 7 module catalog.
STEP 7 therefore does not recognize the SM 374 order number. "Simulate" the simulator
module function required for your configuration as follows:
● To use the SM 374 with 16 inputs, define the order number of a digital input module with
16 inputs in
STEP 7 ,
for example: 6ES7321-1BH02-0AA0
● To use the SM 374 with 16 outputs, define the order number of a digital output module
with 16 outputs in
STEP 7 ,
for example: 6ES7322-1BH01-0AA0
● To use the SM 374 with 8 inputs and 8 outputs, define the order number of a digital
input/output module with 8 inputs and 8 outputs in
STEP 7 ,
for example: 6ES7323-1BH00-0AA0
