Analog modules
6.14 Analog output module SM 332; AO 4 x 12 Bit; (6ES7332-5HD01-0AB0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
465
Technical specifications
Destruction limit against external voltages/currents
• Voltage at outputs to M
ANA
• Current
max. 18 V continuous;
75 V for the duration of max. 1 s (duty factor 1:20)
max. 50 mA d.c.
Wiring of the actuators
• for voltage output
– 4-wire connection (measuring lead)
• for current output
– 2-wire connection
using a 20-pin front connector
supported
supported
Parameter reassignment in RUN
If you reassign parameters in RUN, the following special characteristic applies.
SF LED is lit:
If a diagnostics was pending prior to reconfiguration, the SF LEDs (on CPU, IM or module)
may be lit even though diagnostics is no longer pending and the module is operating
correctly.
Solution:
● Only assign new parameters if no diagnostics is pending, or
● unplug module and plug it in again.
6.14.1 Output ranges of SM 332; AO 4 x 12 Bit
Introduction
You can configure the outputs for operation as voltage or current outputs, or disable them.
You program the outputs at the "output type" parameter in
STEP 7 .
The output type "Voltage" and output range "± 10 V" are set by default at the module. You
can always use this combination of output type and range without having to program the SM
332; AO 4 x 12 Bit in
STEP 7 .
Output ranges
Program the voltage and current output ranges in STEP 7 .
Table 6- 36 Output ranges of SM 332; AO 4 x 12 Bit
Selected type of output
Output range
Voltage 1 V to 5 V
0 V to 10 V
± 10 V
Current 0 mA to 20 mA
4 mA to 20 mA
± 20 mA
