Analog modules
6.14 Analog output module SM 332; AO 4 x 12 Bit; (6ES7332-5HD01-0AB0)
S7-300 Module data
464 Manual, 06/2017, A5E00105505-AJ
Technical specifications
Interference frequency suppression, error limits
Crosstalk between outputs > 40 dB
Operational limit (across entire temperature range, relative to measurement range end value in the selected output range)
• Voltage output
• Current output
± 0.5 %
± 0.6 %
Basic error limit (operational limit at 25 °C, relative to the measurement range end value in the selected output range)
• Voltage output
• Current output
± 0.4 %
± 0.5 %
Temperature error (relative to output range)
± 0.002 %/K
Linearity error (relative to output range)
± 0.05 %
Repeat accuracy (in settled state at 25 °C, relative to output range)
± 0.05 %
Output ripple; range 0 Hz to 50 kHz (relative to output range)
± 0.05 %
Status, interrupts, diagnostics
Interrupts
• Diagnostic interrupt
Programmable
Diagnostic functions
• Group fault display
• Reading diagnostic information
programmable
Red LED (SF)
Supported
Setting substitute values
Yes, programmable
Actuator selection data
Output ranges (rated values)
• Voltage
± 10 V
0 V to 10 V
1 V to 5 V
• Current
± 20 mA
0 mA to 20 mA
4 mA to 20 mA
Load impedance (in the rated range of the output)
• For voltage outputs
– Capacitive load
Min. 1 kΩ
Max. 1 µF
• For current outputs
– at CMV < 1 V
– inductive load
max. 500 Ω
max. 600 Ω
max. 10 mH
Voltage output
• Short-circuit protection
• Short-circuit current
Yes
max. 25 mA
Current output
• noload voltage
max. 18 V
