6.14 Analog output module SM 332; AO 4 x 12 Bit; (6ES7332-5HD01-0AB0)
S7-300 Module data
Manual, 06/2017, A5E00105505-AJ
463
Technical specifications
Technical specifications
Dimensions and weight
Dimensions W x H x D (mm) 40 x 125 x 117
Weight
ca. 220 g
Module-specific data
Supports parameter reassignment in RUN
yes
Reaction of non-programmed outputs Return the output value which was valid before the
parameterization
Supports isochronous mode
no
Number of outputs
4
Cable length
• shielded
max. 200 m
Voltages, currents, electrical potentials
Rated load voltage L+
• Reverse polarity protection
24 V DC
Yes
Electrical isolation
• between channels and the backplane bus
• between channels and electronics power supply
• between channels
• between channels and load voltage L+
Yes
Yes
no
Yes
Maximum potential difference
• between S- and M
ANA
(CMV)
3 V DC
Isolation test voltage
500 V DC
Current consumption
• from the backplane bus
• from load voltage L+ (no-load)
max. 60 mA
max. 240 mA
Power loss of the module
typ. 3 W
Generation of analog values
Resolution (including overshoot range)
• ± 10 V; ± 20 mA;
• 4 mA to 20 mA; 1 V to 5 V
• 0 V to 10 V; 0 mA to 20 mA
11 bits + sign
12 bits
Conversion time (per channel)
max. 0.8 ms
Transient recovery time
• with resistive load
• with capacitive load
• with inductive load
0.2 ms
3.3 ms
0.5 ms (1 mH)
3.3 ms (10 mH)
