Digital modules

3.15 Digital input module SM 321; DI 16 x DC 48-125 V; (6ES7321-1CH20-0AA0)

S7-300 Module data

110 Manual, 06/2017, A5E00105505-AJ

Technical specifications

Sensor selection data

Input voltage

• Rated value

48 VDC to 125 VDC

• "1" signal

30 V to 146 V

• "0" signal

-146 V to 15 V

Input current

• "1" signal

typ. 3.5 mA

Input delay

• "0" to "1" transition

• "1" to "0" transition

0.1 ms to 3.5 ms

0.7 ms to 3.0 ms

Input characteristics

to IEC 61131, type 1

Connection of 2-wire BEROs

• Permissible quiescent current

supported

max. 1 mA

Wiring the signal transducers

using a 20-pin front connector
